Cross-slotted posts hold inverted empty bottles above and collect water around them
Default solid volume
About 94 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Bottle Neck Vented Rest Box
190 × 120 × 60 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Length
90–250 mm
Width
55–210 mm
Height
12–160 mm
Interior layout
Number of bottle positions
1–3
Functional configuration
Post outer diameter
18–38 mm
Cross vent slot width
5–14 mm
Water collection rim height
8–22 mm
Construction details
Wall and floor thickness
1.6–4 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
One-piece, printed flat on its base. Empty bottles go upside down on the cross posts; the post outer diameter must be smaller than the bottle mouth clear diameter; the slots run from the post tops down to the water collection space at the bottom.
The bottle's outer diameter should be smaller than the position center distance; measure the center of gravity and tip resistance; empty the water promptly. Before use, check food contact, leakage or drying efficiency.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
