Capsules line up neatly in the paper box with their axes front to back; measure maximum outer diameter and total axial length; not for random filling or any brand size.
With the paper box bottom opened, insert it down to the four-sided step; capsules drop through the outlet into the lower compartment. Paper box size, capsule size and compartment count are linked; export is refused when there is not enough space; check the arrangement direction against real items and hold the paper box when taking from it.
01 / SPECIFICATIONS
Specifications
See the default structure and usable space.
With the paper box bottom opened, insert it down to the four-sided step; capsules drop through the outlet into the lower compartment. Paper box size, capsule size and compartment count are linked; export is refused when there is not enough space; check the arrangement direction against real items and hold the paper box when taking from it.
Separate sorting compartments
3 compartments
Paper box fit outer width × outer depth
41 × 40 mm
Drop outlet clear width × clear depth
37.8 × 36.8 mm
Nominal capsule envelope
Ø36 × 30 mm
Paper box sleeve insertion depth
40 mm
Pick-up opening clear height
38.6 mm
Default solid volume
About 139 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Paper box sleeve and bottom-dispensing compartment seat
135 × 90 × 86.4 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Paper box fit
Paper box outer width
32–60 mm
Paper box outer depth
30–65 mm
Paper box sleeve insertion depth
25–80 mm
Capsules and sorting
Maximum capsule diameter
20–55 mm
Total capsule axial length
18–55 mm
Number of separate sorting compartments
1–4 compartments
Structure
Base front-to-back depth
60–180 mm
Structural thickness
2–3.2 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
With the paper box bottom fully opened, insert it from above down to the step; enter the sleeve opening from the paper box outer size, with 0.4 mm per side. Supply your own paper box and capsules.
Capsules line up neatly in the paper box with their axes front to back; measure maximum outer diameter and total axial length; not for random filling or any brand size.
Hold the paper box, gently lift the bottom capsule about 3.2 mm, then take it forward; a 3 mm lip stops items sliding straight out; automatic one-by-one dispensing is not promised.
Base plate down; check supports for the bridge above the pick-up opening when slicing. Test-print to check paper box friction/deformation, odd-shaped capsules, full-box stability and real use first.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
The ZIP contains the complete STL and STEP files, a size list and notes. Version {{version}}; use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
{{parameter_groups}}
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
{{adjust_customize}}
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
{{instructions}}
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
