Two stepped rows with graduated blind holes sort by drill shank size
Default solid volume
About 608 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Stepped Drill Bit Locating Box
160 × 90 × 55 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Length
90–250 mm
Width
55–210 mm
Height
12–160 mm
Interior layout
Holes per row
3–8
Functional configuration
First hole clear diameter
2–8 mm
Hole diameter increment
0.5–2 mm
Insertion depth
8–28 mm
Construction details
Wall and floor thickness
1.6–4 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
One-piece print with no assembly, flat base down; drill shanks insert down into blind holes. Holes are clear diameters; measure your drill shanks and leave a loose fit.
The lower front row is easy to reach; the back row only suits drill bits with enough length exposed; not a drill gauge.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
