Inside the heart outline choose one open compartment, left and right compartments or three adjustable compartments for jewelry and keepsakes.
Actual zones
3
Usable depth under the lid
36.8 mm
Divider position
40% from the tip
Default solid volume
About 162 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Heart-shaped zoned box body
150 × 137.1 × 42.6 mm
STL · STEP
Heart-shaped locating lid
150 × 137.1 × 5.4 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Length
80–240 mm
Total height
20–100 mm
Wall and floor thickness
1.6–4.8 mm
Functional configuration
Interior layout
One / left and right / three compartments
Three-compartment divider position
20–65 %
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
Length is the outermost left-to-right distance, and width follows the heart proportions; wall thickness stays normal to the outline.
The three-compartment divider position is measured from the tip of the heart; with one or two compartments, this position does not change the layout.
The locating lid has a fixed 0.4 mm single-side clearance and 3 mm insertion, with no latch or seal; divider tops are below the lid.
Box bottom down; lid locating face down; check the overhangs when slicing. Check the real fit before use.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
