A removable crossbar spans the opening, with two round dowels inserted into blind pockets in the box edge
Default length
180 mm
Default width
120 mm
Default height
70 mm
Default crossbar front-to-back width
22 mm
Default tenon diameter
7 mm
Default tenon insertion depth
10 mm
Default solid volume
About 215 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Edge pocket outer box
180 × 120 × 67.6 mm
STL · STEP
Twin tenon limit beam
180 × 22 × 12.4 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Length
80–250 mm
Width
55–230 mm
Height
15–240 mm
Functional configuration
Crossbar front-to-back width
15–32 mm
Tenon diameter
5–9 mm
Tenon insertion depth
6–14 mm
Tenon single-side clearance
0.25–0.7 mm
Construction details
Wall and floor thickness
1.8–3.6 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
The crossbar's two tenons insert vertically into the edge pockets and pull straight up. The crossbar only separates/limits long items; it is not a handle or transport latch; print with the beam face down.
Units are millimeters. Measure clearance from your actual items first; check slicing before printing and test-fit the key mating parts.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
