Paired square ear pockets join the side of the round lid compartment, with the central raised area cleared in a deep well. On a photography table, lens caps with pinch ears are sorted, with the outer edge on a ring shoulder and the ears in square pockets; set by lid diameter, ear width and central relief depth; not a camera mount.
Default outer length
140 mm
Default outer width
115 mm
Default total outer height
32 mm
Default lid rim compartment clear diameter
62 mm
Default single ear pocket clear width
18 mm
Default central relief depth
8 mm
Default solid volume
About 427 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Use-specific storage box
140 × 115 × 32 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Outer length
80–245 mm
Outer width
60–235 mm
Total outer height
15–130 mm
Functional configuration
Lid rim compartment clear diameter
45–82 mm
Single ear pocket clear width
12–26 mm
Central relief depth
5–14 mm
Construction details
Wall and floor thickness
1.8–3.6 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
One-piece, no hardware. The lens cap's outer edge rests on a ring shoulder, with the pinch ears clear in square pockets on both sides; loads and unloads from the top, with no snap connection or locking.
Units are millimeters; matching parts use files generated in the same export. Set clearance by your items' maximum size and leave room to take them in and out.
Check orientation and supports before printing, and test-print key mating parts first.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
