Drawers of different heights are generated column by column to fit a sloped-top space, with compartments following each drawer.
Top wall normal thickness
2.4 mm
Clear width per drawer
57.9 mm
Default solid volume
About 614 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Sloped-top cabinet
200 × 140 × 120 mm
STL · STEP
Angled-front drawer 1
62.7 × 136.8 × 74.3 mm
STL · STEP
Angled-front drawer 2
62.7 × 136.8 × 94.1 mm
STL · STEP
Angled-front drawer 3
62.7 × 136.8 × 113.9 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Length
120–280 mm
Width
90–200 mm
Height
60–220 mm
Functional configuration
Low side height
35–160 mm
Number of drawer columns
1–4
Front and rear compartments per drawer
1–4
Construction details
Wall and floor thickness
1.6–4 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
For spaces with a sloped top; the low side is on the left; drawers from different columns are not interchangeable.
Pulls fully out at the front, supported underneath and stopped at the back; no anti-separation lock. Check cabinet bridging and supports when slicing, and test-print to check load-bearing first.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
4 × DIN 97 A2 slotted 90° countersunk wood screws (nominal 3 mm, default 3×12 mm; after changing parameters choose 3×10/12/16 mm from the current solid wood desk list)
1 standard 0.6 × 3.5 mm flat screwdriver supplied separately
Screw head Ø5.6 × 1.65 mm, actual shank 2.6–3.0 mm, verified in-stock Westfield WF78847/WF78848/WF1106; all 4 printed parts included
See the model page for specifications and assembly steps; after resizing, follow the current assembly list.
