M4 axle rod supplied separately: 176 mm, plus two washers/nuts
01 / SPECIFICATIONS
Specifications
See the default structure and usable space.
The central horizontal axle lets each compartment dispense independently, with a through M4 rod joining the flaps and upper frame; the full-level mark reserves space under the swing lid.
Sorting compartments
2 compartments / clear width 75.5 mm
Reference fill depth
83.0 mm (above the base plate)
M4 axle rod supplied separately
176 mm, plus two washers/nuts
Swing lid front-to-back length
101.9 mm
Axle center to lid plate center
6 mm
Default solid volume
About 368 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Sorting box body with full-level marks
160 × 110 × 130 mm
STL · STEP
Liftable bearing upper frame
167 × 117 × 22.5 mm
STL · STEP
Compartment 1 swing lid
74.5 × 101.9 × 12 mm
STL · STEP
Compartment 2 swing lid
74.5 × 101.9 × 12 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Box size
Box left-to-right length
90–230 mm
Box front-to-back depth
70–160 mm
Box height
70–210 mm
Wall thickness
2.4–4 mm
Sorting and swing lid
Number of sorting compartments
1–3 compartments
Axle center to lid plate center
4–12 mm
Movement clearance
0.3–0.8 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
Supply an M4 through rod about 176 mm long, two washers and two nuts; hardware is not included in the print files or print envelope.
Put each swing lid into the upper frame, align the axle holes, pass the axle rod in from the side and fix both ends with washers and nuts; keep 0.5–1 mm of axial play; do not clamp the swing lid. Then fit the upper frame over the box opening; lift the whole set to empty it.
The horizontal line on the inner front wall marks full; keep material below it so it does not block the lower edge of the swing lid; for dry scraps on a desk; not a liquid, airtight or odor-proof container.
The axle center sits above the lid flap's uniform-material center of gravity; return also depends on infill density and friction; test-print to check actual fill density, axle hole friction and return smoothness first.
Box base down; choose orientation and supports in the slicer for the upper frame axle holes and the swing lid cross axle; test-print the hole sizes and fit first; support-free printing is not claimed.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
