Arc-Slot Tip-Out Bin model preview, default size 168.8 × 96.4 × 119.4 mm, 3 parts
3 partsSTL + STEPMillimetersVersion 1.0.1
01 / SPECIFICATIONS

Specifications

See the default structure and usable space.

Column count, front stop height and maximum tilt angle drive the real geometry together; the frame must be fixed to a vertical surface with your own M4 screws.

Separate columns
3 columns
Clear width per column
50.1 mm
Front stop height
63.8 mm
Top pick-up opening clear depth
50.1 mm
Maximum forward tilt angle
45°
Default solid volume
About 305 cm³ (check in your slicer)

Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.

02 / MODEL FILES

Files and dimensions

The default download includes all matching parts.

Default model parts and outer dimensions
PartsOuter sizeFile formats
Arc slot fixed frame165.6 × 96.4 × 119.4 mmSTL · STEP
Tip-forward column compartment164.6 × 92 × 69.3 mmSTL · STEP
Headed pull-out cross axle168.8 × 8.4 × 8.4 mmSTL · STEP

The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.1 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.

03 / ADJUSTMENTS

Adjustable options

Make the same model fit your space.

Outer size
Compartment width
90–220 mm
Swing radius
60–120 mm
Wall and floor thickness
2.4–4.8 mm
Functional configuration
Number of interior columns
1–6 columns
Front stop height ratio
60–85 %
Maximum forward tilt angle
30–55 °

Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.

01

Adjust size

Sign in to open this model in the studio.

02

Preview

Adjusting and 3D preview are free.

03

Check export options

Confirm the files and available download options on the current page.

Adjust this model

Size and structure parameters update all matching parts of this model together.

04 / PRINT & ASSEMBLY

Printing and assembly

Check slicing and fit after downloading.

  1. The compartment slides in horizontally from the front, and the guide pins on both sides enter the start of the arc slots; align the bottom holes, then insert the cross axle from the left.
  2. First fix the frame to a vertical support with two M4 screws, then fit the compartment; choose screw length and anchors by the substrate and supply them yourself.
  3. The column count changes the actual inner cavity; the front stop height ratio affects volume and the access opening; the maximum tilt angle also changes the arc slot stops.
  4. Tip forward to the end of the arc slot to take items; with it closed and the cross axle pulled out, the whole compartment slides out from the front for cleaning. Leave full axle-pulling space on the left.
  5. The cross axle has no tail lock; check that it has not backed out before moving; no closing latch or seal. Do not tip the frame forward fully loaded before it is fixed.
  6. Print the cabinet frame back and the compartment side flat on the plate; check supports for the horizontal cross axle; before use, check the rotating fit, pin retention and load-bearing.

Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
