One-piece fixed twin rails stay aligned; drawer dividers and screw holes are adjustable.
Front and rear mounting hole center distance
120.0 mm
Left and right mounting hole center distance
178.0 mm
Default solid volume
About 404 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
One-piece twin-rail fixed frame
210 × 190 × 65 mm
STL · STEP
Pull-out divided drawer
204.4 × 186.8 × 56.8 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.1 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Length
130–280 mm
Width
100–260 mm
Height
35–100 mm
Functional configuration
Drawer columns across
1–5
Drawer front and rear division
1–5
Front and rear mounting hole spacing
40–210 mm
Screw through hole diameter
3–6 mm
Construction details
Wall and floor thickness
1.6–4 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
Take the drawer out first, then fix the top to the underside of the desk with 4 of your own screws; set hole diameter with allowance for your actual screws; head diameter at most hole + 4 mm and head height no more than 3 mm.
A one-piece rear beam keeps the two rails aligned; the drawer sits on the bottom rails and pulls fully forward, with no anti-pull-out lock; support it when removing.
Confirm the desk board material, thickness and screw length so they do not go through the desktop; test-print to check fixing strength and drawer load first.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
1 × M3 fully threaded socket head screw (default M3×16 mm; after changing parameters choose the length from the current list; head diameter ≤ 5.5 / height ≤ 3 mm)
4 × 3.5 mm round-head wood screws (default 16 mm shank under the head is only an 18 mm solid wood example; head diameter ≤ 7 / height ≤ 3 mm; choose the length by actual board thickness and the current list)
See the model page for specifications and assembly steps; after resizing, follow the current assembly list.
