Paper boxes easily jam drawers, and bag shapes vary. Original design with continuous side rails and a rear stop, configured by the folded bag stack and drawer clear height; no magnets needed. Wide windows leave room to pinch, but bag edges still need separating by hand.
01 / SPECIFICATIONS
Specifications
See the default structure and usable space.
Paper boxes easily jam drawers, and bag shapes vary. Original design with continuous side rails and a rear stop, configured by the folded bag stack and drawer clear height; no magnets needed. Wide windows leave room to pinch, but bag edges still need separating by hand.
Recommended bag stack envelope
230 × 100 × 58.2 mm
Pull window clear opening
100 × 35 mm
Sliding lid single-side clearance
0.4 mm
Printed parts / purchased
2 parts / no required purchases
Default solid volume
About 277 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Side-Rail Closed-Bottom Bag Box
240 × 110 × 70 mm
STL · STEP
Window sliding lid
236.2 × 105.6 × 3 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Overall outer length
180–280 mm
Overall outer width
80–160 mm
Overall outer height
40–90 mm
Functional configuration
Pull window clear length
60–160 mm
Pull window clear width
20–65 mm
Construction details
Wall and floor thickness
2.8–4 mm
Fit single-side clearance
0.25–0.65 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
2 complete printed parts: 1 side-rail closed-bottom box and 1 window sliding lid; no hardware, magnets or glue to buy. The whole set uses the same parameters.
Recommended flat stacked envelope for clean food bags up to 230 × 100 × 58.2 mm; measure the folded zipper and stack thickness first; do not judge by the bag's nominal capacity.
Pull window clear opening 100 × 35 mm, with a separate finger hole at the front. Hold the box and pinch the bag edge through the window; soft bags need bending; automatic single-sheet separation is not guaranteed.
Push the sliding lid in horizontally from the front slot to the rear wall; 0.4 mm per side sideways and vertically; side slots engage 0.8 mm deep. Slide out the whole lid to refill or clean, leaving 236.2 mm of exit space in front.
This box is for horizontal use inside a drawer, with no transport locking or sealing. Do not stack heavy items on the lid.
The box and lid plates are both zeroed flat side down; verify the overhangs of the box mouth and inner rails and the flatness of the lid plates with slicing and a clearance test piece. Check slicing and test-print before printing; before use, check long-term warping and actual pulling.
Default haze blue box with a light sand lid; optional sage green with cream, or warm gray with coral orange. Preview colors do not affect manufacturing geometry.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
