A cylindrical lower body opens through an outward arc to its widest rim, unlike a wide-footed bell jar.
Conservative Straight Clear Length per Compartment
63.2 mm
Conservative Straight Clear Width per Compartment
35.4 mm
Usable Depth Below Lid Ring
97.4 mm
Default solid volume
About 222 cm³ (check in your slicer)
Listed part dimensions are outer bounds; usable interior space is given in this model's specifications.
02 / MODEL FILES
Files and dimensions
The default download includes all matching parts.
Default model parts and outer dimensions
Parts
Outer size
File formats
Curved Shared-Wall Jar Body
130 × 130 × 104.2 mm
STL · STEP
Curved Jar Locating Ring Lid
130 × 130 × 11.8 mm
STL · STEP
The ZIP contains the complete STL and STEP files, a size list and notes. Version 1.0.0 Use the complete set of files of the same version and size for matching parts. Preview colors are for reference only; STL files carry no color.
03 / ADJUSTMENTS
Adjustable options
Make the same model fit your space.
Outer size
Maximum Outer Diameter
115–165 mm
Overall Height Including Lid and Grip
95–145 mm
Interior layout
Interior layout
Open cavity / Two compartments / Four compartments
Divider top height
18–42 mm
Model parameters
Radial Curve Offset
8–13 mm
Construction details
Ring clearance per side
0.3–0.7 mm
Base wall and floor thickness
2.4–3.4 mm
Ranges are set by this model's structure; each combination must pass the studio's structure checks; matching parts update with the parameters.
01
Adjust size
Sign in to open this model in the studio.
02
Preview
Adjusting and 3D preview are free.
03
Check export options
Confirm the files and available download options on the current page.
Size and structure parameters update all matching parts of this model together.
04 / PRINT & ASSEMBLY
Printing and assembly
Check slicing and fit after downloading.
Insert items from above. Key dimensions describe conservative straight-through clearance; rounded corners, dividers and shaped ends also occupy space. Allow handling clearance for the widest part of each item.
Two parts are included: the jar body and lid. The locating ring inserts by 4 mm, the plate rests on the rim and the grip lifts upward. The curved interior uses a conservative radial inset, so local thickness is not uniform.
Clearances describe conservative rectangular regions accessible vertically to the floor. Check items in each enabled compartment; the widest outer diameter is not the entrance or compartment diameter.
Place the jar base down; choose lid orientation and supports in the slicer. The lid is neither sealed nor latched.
Nominal ring clearance at the straight neck is 0.45 mm per side; test the ring fit before printing the full kit.
All custom parts are included in the download; no purchased parts are required. Preview colors are for display only; manufacturing STL/STEP files are uncolored.
Slicing and physical test printing have not been performed. Check overhangs, supports and fit before printing; support-free printing, load capacity, sealing and food-contact safety are not promised.
Import into your slicer in millimeters and check build volume, orientation and supports for each part. Test-print lids, drawers and connectors first, and print the full set once the fit is confirmed.
